tna hydro-wash^WTP 3

shear washing system

Benefits
Features
Specifications
Applications

Florigo hydro-wash® WTP 3 is an advanced slice washing system that removes starch to prevent potato slices from sticking together and collects only full size potato slices that are then placed in a single layer for even frying.

This potato slice washing system, or as it’s better known – the tna hydro-wash^WTP3 – removes starch to prevent potato slices from sticking together. In addition, it collects only full-size potato slices and places them in a single layer for even frying. Perfect for smaller capacity production lines, this system is always reliable.

Benefits

Removes starch and collects only full-size slices for optimal preparation ahead of frying.
Isolates full-size slices and prepares them in a single layer for even frying.
Minimal maintenance requirements for higher productivity.
Separates starch for use in other applications and cleans water for reuse – lowering water consumption.

Benefits

Removes starch and collects only full-size slices for optimal preparation ahead of frying.
Isolates full-size slices and prepares them in a single layer for even frying.
Minimal maintenance requirements for higher productivity.
Separates starch for use in other applications and cleans water for reuse – lowering water consumption.

standard features

De-watering vibrator
Water circulation system
Water tank
Stainless steel execution (exception fans, pumps, drives, valves, bearings, belts)

optional features

Starch recovery system

specifications

tna hydro-wash^WTP 3
model name	WTP VS 300
capacity slices kg/hr (lbs/hr)	<1200 (2645)
infeed height mm (in)	3050 (120)
outfeed height mm (in)	1645 (65)
outfeed width mm (in)	550 (22)
total length mm (in)	4545 (179)
total width mm (in)	2246 (88)
washing pump m3/hr (cfm)	60 (2119)
fresh water m3/hr (cfm) (wo. starch removal/1000kg (2205lbs) slices)	1.75 (62)
fresh water m3/hr (cfm) (with starch removal/per 1000kg (2205lbs) slices)	0.3 (11)
water content L (US gl)	ca. 800 (176)
All above specifications are subject to change and may differ according to the product. Please confirm when placing your order.
