tna ultra-clean^WT 3

drum washer

Benefits
Features
Specifications
Applications

Designed for maximum efficiency, the tna ultra-clean^WT 3 removes clay shells, sand and soil from potatoes and other root vegetables – without damage. The drum washer system combines with the tna ultra-clean^OC 3 to form a complete cleaning solution, well-suited to high-capacity lines. Thanks to its simple design, the tna ultra-clean^WT 3 requires little maintenance, helping to reduce production downtime.

Benefits

Efficiently cleans product without causing damage.
Ensures thorough cleaning, even with irregular shapes vegetables.
Optimises retention time and controls cleaning based on amount of soil on the product.
Easy to maintain with a single access point to apply grease.

Benefits

Efficiently cleans product without causing damage.
Ensures thorough cleaning, even with irregular shapes vegetables.
Optimises retention time and controls cleaning based on amount of soil on the product.
Easy to maintain with a single access point to apply grease.

standard features

Different shaped profiles in the drum for specific products
Spray pipe mounted inside and outside the drum
Adjustable slide gate that regulates the retention time of the product in the drum washer
Frequency controller on drum drive
Sturdy support wheels design
Centralised greasing point
Stainless steel execution (exception fans, pumps, drives, valves, bearings, belts)

optional features

Rotary brush mounted inside the drum
Reclaimer with pump

specifications

tna ultra-clean^WT 3
model name	WT 2000-08	WT 3000-08	WT 2000-12	WT 3000-12	WT 3000-15	WT 4000-12	WT 4000-15
capacity kg/hr (lbs/hr)	7000 (15400)	10000 (22000)	13000 (28600)	17000 (37450)	28000 (61700)	28000 (61700)	40000 (88190)
motor drum kW (hp)	3 (4)				4.4 (6)
motor brush kW (hp)	2.2 (3)				3 (4)
water consumption refreshment m³/1000kg/hr (cfm/2205lbs)	0.5 (18)
length mm (in)	3850 (152)	4850 (191)	3850 (152)	4850 (191)		5850 (230)
width mm (in)	1400 (55)		1800 (71)		2100 (83)	1800 (71)	2100 (83)
height mm (in)	2050 (80)		2450 (96)		2750 (108)	2450 (96)	2750 (108)
empty weight kg (lbs)	1700 (3748)	2100 (4630)		2500 (5512)	2800 (6173)	2900 (6394)	3200 (7055)
operation weight kg (lbs)	2100 (4630)	2500 (5512)		2900 (6394)	3200 (7055)	3300 (7276)	3600 (7938)
all above specifications are subject to change and may differ according to the product, please confirm when placing your order.
