tna ultra-clean OC 3
cyclone destoner
tna ultra-clean OC 3
A continuous vegetable destoner, the tna ultra-cleanOC 3 uses a cyclone effect to ensure the efficient removal of stones and soil from root vegetables, including potatoes. The funnel-shaped hopper is filled with spinning water to allow the root vegetables to rise to the top, forcing the stones to separate and sink to the bottom. Pair with the tna ultra-cleanWT 3 for a complete cleaning system that helps optimise production lines – even at high-capacities.
Efficiently separates stones and clay shells from root vegetables.
Adjustable water flow to meet changing requirements.
Minimises damage to cutting and slicing equipment on processing lines.
standard features
- Cyclone de-stoning effect
- Adjustable upward water flow
- Continuous stone removal
- Heavy duty pump suitable for polluted water
- Water recirculation system
- Rotary paddle
- Stainless steel execution (exception fans, pumps, drives, valves, bearings, belts)
optional features
- Water recirculation system via reclaim reel
| tna ultra-cleanOC 3 | |||
|---|---|---|---|
| model name | OC 1500 | OC 2300 | OC 3500 |
| capacity kg/hr (lbs/hr) | 10000 (22000) | 25000 (55000) | 50000 (110231) |
| motor agitator kW (hp) | 1.5 (2) | 1.5 (2) | 3 (4) |
| circulation pump kW (hp) | 5.5 (7) | 7.5 (10) | 11 (15) |
| motor stone removal belt kW (hp) | 0.75 (1) | ||
| length mm (in) | 4760 (187) | 5180 (204) | 6970 (275) |
| width mm (in) | 1500 (59) | 2300 (91) | 3500 (138) |
| height mm (in) | 4150 (163) | 4570 (180) | 4900 (193) |
| empty weight kg (lbs) | 1250 (2756) | 1800 (3968) | 3000 (6614) |
| operation weight kg (lbs) | 3500 (7700) | 4800 (10600) | 8000 (17600) |
| all above specifications are subject to change and may differ according to the product, please confirm when placing your order. | |||
