tna accura-dryBD 3

belt dryer

Introducing the tna accura-dryBD 3: a belt dryer for French fries that effectively removes moisture before frying to help create an appealing texture. By reducing product retention and oil heating times, the system enables increased production capabilities. Plus, with its hygienic design, the tna accura-dryBD 3 shortens cleaning cycles to minimise downtime. Pair with the tna conti-proFF 3 for optimum results.

Benefits

  • Dries French fries evenly, for a superior end product.
  • Choose your preferred drying process to suit different air temperatures.
  • Improves energy efficiency, to reduce your plant’s environmental impact.
  • Enables shorter cleaning times, thanks to its enhanced hygienic design.

Introducing the tna accura-dryBD 3: a belt dryer for French fries that effectively removes moisture before frying to help create an appealing texture. By reducing product retention and oil heating times, the system enables increased production capabilities. Plus, with its hygienic design, the tna accura-dryBD 3 shortens cleaning cycles to minimise downtime. Pair with the tna conti-proFF 3 for optimum results.

Benefits

  • Dries French fries evenly, for a superior end product.
  • Choose your preferred drying process to suit different air temperatures.
  • Improves energy efficiency, to reduce your plant’s environmental impact.
  • Enables shorter cleaning times, thanks to its enhanced hygienic design.

standard features

  • Plate belt with special slot design
  • Air refreshment is in counter flow with product
  • Heat source using steam
  • One fresh air inlet for each section
  • Open and accessible construction with CIP
  • Modular design
  • Stainless steel execution (exception fans, pumps, drives, valves, bearings, belts)

optional features

  • Heating source using water by means of heat recovery from fryer

specifications

tna accura-dryBD 3
model name FBD 2000 FBD 2500 FBD 3000
capacity kg/hr (lbs/hr) 3000-30000 (6614-66139)
belth width mm (in) 2000 (79) 2500 (98) 3000 (118)
number of modules 2 2-3 4-7 6-11 8-14 10-19 12-23 15-28
length per module mm (in) 1900 (75) 2200 (87)
total width mm (in) 4080 (160) 4580 (180) 5080 (200)
all above specifications are subject to change and may differ according to product, please confirm when placing your order.

applications

downloads

  • French Fries brochure
