tna conti-pro FF 3

atmospheric continuous frying system (French fries)

tna conti-pro FF 3

Optimise processing efficiencies with the tna conti-proFF 3. This continuous frying system – specifically designed for french fry applications – features zonal flow oil injection technology for consistent cooking at high temperatures. Pair with the tna accura-dryBD 3 to effectively remove moisture before frying to create appealing product texture every time.

  • Create unique flavours, texture and high-quality products with laminar oil flow and multi-flow oil injection for capacities of up to 25,000 kg/hr (55,000 lbs/hr)

  • Surpass operational efficiencies with our patented opti-flow® oil injection module for optimised laminar oil flow over the full length of the frying kettle

  • Increase profits by achieving great frying results; shorter oil turnover times in combination with a zonal flow oil injection system, which clears debris from the fryer bottom, results in improved oil quality

  • Lower your TCO with an optimised design for easy operation and maintenance with three positions of fryer hood for production, inspection, cleaning and maintenance

  • Effortlessly achieve your OEE goals with an internal clean in place (CIP) system for ease of access and cleaning; no oil remains after draining the fryer

  • Create healthy french fries with a single belt design that removes excess fat from french fries while frying at constant temperature for reduced acrylamide formation

standard features

  • Optimal product and oil flow
  • Zonal flow design
  • Self-supporting product belt
  • Continuous oil filtration through belt filter
  • Durable construction design with long lifecycle and meets highest safety standards
  • Hood lifting device
  • Insulated hood
  • Clean in place (CIP) with integrated piping in hood
  • Condensate collecting pan
  • Oil circulation system
  • Oil tank for used oil
  • Thermal oil heat exchanger
  • Stainless steel execution (exception fans, pumps, drives, valves, bearings, belts)

optional features

  • Paper filter
  • Steam heat exchanger
  • Oil tank for fresh oil
  • Oil injection collimator
tna conti-proFF 3
model name BAF-ZF 0300 BAF-ZF 0540 BAF-ZF 0900 BAF-ZF 1350 BAF-ZF 1880 BAF-ZF 2250
fryer output capacity kg/hr (lbs/hr) (standard for French fries 9×9 mm (0.35×0.35 in)) 3000 (6600) 6000 (13200) 10000 (22000) 15000 (33000) 20000 (44000) 25000 (55000)
transport system, product netto width (mm/in) 1000 (39) 1200 (47) 1500 (59) 1800 (71) 2500 (98) 2500 (98)
length mm (in) 8335 (328) 9835 (387) 11335 (446) 12835 (505) 12835 (505) 14335 (564)
width mm (in) 2182 (86) 2382 (94) 2682 (106) 2982 (117) 3682 (145) 3682 (145)
height mm (in) 2435 (96) 2455 (97) 2480 (98) 2510 (99) 2570 (101) 2570 (101)
frying oil belt filter (full flow)
model name FB 0400 HVI FB 0500 HVI FB 0750 HVI FB 1000 HVI FB 0750 HVI (2x) FB 1000 HVI (2x)
transport system netto width (mm/in) 360 (14) 460 (18) 710 (28) 960 (38) 710 (28) (2x) 960 (38) (2x)
length mm (in) 1800 (710)
width mm (in) 1130 (45) 1230 (48) 1480 (58) 1730 (68) 1480 (58) 1730 (68)
height mm (in) 2255 (890)
frying oil – thermal oil heat exchanger
model name WW 0927 BS WW 1855 BS WW 3091 BS WW 4637 BS WW 6182 BS WW 7728 BS
single heat exchanger capacity kW (hp) 927 (1243) 1855 (2488) 3091 (4145) 4637 (6218) 6182 (8290) 7728 (10363)
paper filter (optional)
model name FBP 45 FBP80
length mm (in) 2150 (85) 3200 (126)
width mm (in) 900 (35) 1435 (57)
height mm (in) 1575 (62) 1415 (56)
all above specifications are subject to change and may differ according to product, please confirm when placing your order.
