tna hydro-clear® OWB 3 | Dewatering System - tna

tna hydro-clearOWB 3

de-watering belt system

Ferguson accura-dry® BD 3 belt dryer is your ultimate drying solution, removing moisture from French fries before frying.

A highly efficient potato dewatering system, the tna hydro-clearOWB 3 removes water from both sides of potato slices before frying, while ensuring products are evenly spaced. By eliminating excess water, the equipment reduces oil heating and product retention times to lower the fryer’s energy consumption.

Benefits

  • Controls the amount of water that feeds into the fryer to suit your preferences.
  • Removes surface water from the product for an optimal frying process.
  • Increases fryer capacity, while lowering energy consumption to optimise production.
  • Helps prevent products clustering to feed a single layer of slices into the fryer.

A highly efficient potato dewatering system, the tna hydro-clearOWB 3 removes water from both sides of potato slices before frying, while ensuring products are evenly spaced. By eliminating excess water, the equipment reduces oil heating and product retention times to lower the fryer’s energy consumption.

Benefits

  • Controls the amount of water that feeds into the fryer to suit your preferences.
  • Removes surface water from the product for an optimal frying process.
  • Increases fryer capacity, while lowering energy consumption to optimise production.
  • Helps prevent products clustering to feed a single layer of slices into the fryer.

standard features

  • Air knives to strip water from slices
  • High-speed belt conveyor to feed a single layer of slices into the fryer
  • Stainless steel execution (exception fans, pumps, drives, valves, bearings, belts)

optional features

  • Double fan air circulation with moisture separation system
  • Dewatering belt for sticks

specifications

tna hydro-clearOWB 3
model name OWB 2300-06 OWB 2300-08 OWB 2300-10 OWB 2300-13 OWB 2300-16 OWB 2300-20
capacity kg/hr (lbs/hr) 1040 (2293) 2075 (4575) 3450 (7606) 5185 (11431) 6915 (15245) 10370 (22862)
dewatering belt kW (hp) 0.55 (0.7)
air knife kW (hp) 3 (4)
length mm (in) 2850 (112)
width mm (in) 1100 (43) 1300 (51) 1500 (59) 1750 (69) 2100 (83) 2500 (98)
height mm (in) 2350 (93)
all above specifications are subject to change and may differ according to product, please confirm when placing your order.

applications

downloads

  • Snacks brochure
