tna robag® TX 3e

vertical form fill and seal (VFFS) packaging system

The tna robag® TX 3e is an industry leading high-performance vertical form fill and seal (VFFS) packaging machine, delivering the latest in automation with real-time EtherCAT connectivity. Reaching up to 150 bags per minute*, the tna robag® TX 3e also offers superior flexibility thanks to its rotary double, single and flat jaw configurations. With an integrated display controller CXE, smart diagnostics system and enhanced serviceability, the tna robag® TX 3e is the system of choice to bag just about any type of snack (or food application) quickly and efficiently.

No matter what type of bag you need, changing out formers is quick and simple with our patented tna robag® auto-connect and unload-assist features.

*Subject to bag type, film and product.

Benefits

  • Packs up to 150 bags per minute*
  • Up to 99% target output efficiency and wastage as low as 0.1%*
  • Small footprint, featuring tna’s patented stripper tube closer and advanced film control features
  • Quick and easy product changeover thanks to tna’s patented unload assist, auto-connect and one-touch recipe change functionalities.
  • Reduces maintenance costs with:
    • Drives and controls common to the tna roflo® and tna intelli-flav® systems
    • Smart diagnostics and remote connectivity
    • Up to 20% reduced cabling with EtherCAT connectivity

*Subject to bag type, film and product.

The tna robag® TX 3e is an industry leading high-performance vertical form fill and seal (VFFS) packaging machine, delivering the latest in automation with real-time EtherCAT connectivity. Reaching up to 150 bags per minute*, the tna robag® TX 3e also offers superior flexibility thanks to its rotary double, single and flat jaw configurations. With an integrated display controller CXE, smart diagnostics system and enhanced serviceability, the tna robag® TX 3e is the system of choice to bag just about any type of snack (or food application) quickly and efficiently.

No matter what type of bag you need, changing out formers is quick and simple with our patented tna robag® auto-connect and unload-assist features.

*Subject to bag type, film and product.

Benefits

  • Packs up to 150 bags per minute*
  • Up to 99% target output efficiency and wastage as low as 0.1%*
  • Small footprint, featuring tna’s patented stripper tube closer and advanced film control features
  • Quick and easy product changeover thanks to tna’s patented unload assist, auto-connect and one-touch recipe change functionalities.
  • Reduces maintenance costs with:
    • Drives and controls common to the tna roflo® and tna intelli-flav® systems
    • Smart diagnostics and remote connectivity
    • Up to 20% reduced cabling with EtherCAT connectivity

*Subject to bag type, film and product.

standard features

  • Mono-rail long life vacuum pull belts
  • 38.1cm (15inch) colour touch screens
  • Smart response film dancer
  • Quick change, lightweight former
  • Single pass film loading
  • Auto positioning vacuum drives
  • Servo-driven quick-change jaws
  • Patented product stripper/tube closer
  • tna intelli-system® continuous motion control software

optional features

  • High performance system
  • Modbus/TCP interface for SCADA applications
  • Product–in-seal (PISD) speed regulating software
  • Full up and down stream integration options, including:
    • tna intelli-weigh® multihead weighers
    • tna hyper-detect® metal detectors
    • tna intelli-date® code applicator
    • tna intelli-read® barcode verification
    • bag collators
    • inserters
    • programmable string bag systems
    • tna take away conveyors
    • check weighers

specifications

tna robag® TX 3e rotary double jaw rotary single jaw rotary flat jaw
180 230 320 180 230 320 230 320
performance max running speed bpm 150 150 150 100 100 100 125 125
utilities average air consumption @6bar (87psi) L/min (cfm) 3 (0.11) 6 (0.22)
controller CXE
power consumption kW (hp) 3.5 (4.7) 2.8 (3.8) 3.5 (4.7)
voltage 3PH 208~480VAC
specifications bag length minimum mm (in) 50 (2)
maximum mm (in) 1000 (39.4)
bag width minimum mm (in) 40 (1.6)
maximum mm (in) 180 (7.1) 230 (9.1) 320 (12.6) 180 (7.1) 230 (9.1) 320 (12.6) 230 (9.1) 320 (12.6)
film roll maximum width mm (in) 384 (15.1) 484 (19.1) 664 (26.1) 384 (15.1) 484 (19.1) 664 (26.1) 484 (19.1) 664 (26.1)
diameter mm (in) 400 (15.7)
maximum weight kg (lbs) 50 (110.2)*
construction material powder coated mild steel or stainless steel
tunnel guard opening mm (in) 610 (24)
height mm (in) lowlander total 1800 (70.9)
former 1760 (69.3)
midlander total 1800 (70.9)
former 1835 (72.2)
highlander total 1800 (70.9)
former 1910 (75.2)
jaw height mm (in) lowlander 680 (26.8)
midlander 680 (26.8)
highlander 830 (32.7)
depth mm (in) 1950 (76.8)
width mm (in) 900 (35.4)
weight kg (lbs) 1000 (2204.6)
all above specifications are subject to change and may differ according to product, please confirm when placing your order. * 35kg is recommended to minimise film tracking variations. ** bag length is indicative and requires testing.
